RVB-ECO5



The RVB-ECO5 vertical baler is a 5 ton force machine which has been designed and constructed to service users with smaller amounts of waste (typically between 70 - 200 kg's per day), but who still need a machine to handle bulky materials.

The machine has a small base area making it ideal for operations where space is limited. The baler has a full indicator light which illuminates when the baling chamber is full. Strapping of the completed bale is made easy with the strapping being fed through slits in the main door. The baling chamber is equipped with rows of reverse facing barbs, which 'hold' the material back to ensure optimum filling and efficiency.

Large size filling opening
Advantage when handling larger boxes

Automatic ejection
Two-hand operation ejects the bale

SPECIFICATION


Recyquip Vertical Baler – RVB-ECO5 Specifications

Series

RVB-ECO

Type

Vertical – Top Loading

Charge Chamber opening size

1000 x 500mm

Bale size (L x W x H)

750 x 700 x 800mm

Bale weight / mass

75 to 140kg (Dependent upon product)

Bale Ejection

Manual

Cycle time

Automatic – 35 sec.

Ram Thrust

5 Tons

Normal Working Pressure

120 bar

Rated Output

1 - 25 Tons per month

Filling Height

900mm

Motor Size

2.2 KW

Oil Tank Capacity

40  Litres

Shipping Weight

Approx. 400 kg

Electrical

Electrical Supply Requirements

220V 50 Hz 10A

Power Point

3 Pin Plug & Socket 10 amp

Dimensions

W – Width

1350 mm

D - Depth

890 mm

H - Height

2350 mm

Country of Origin

Manufactured in South Africa
