RMB-36DA HORIZONTAL BALER
The RMB-36DA Horizontal Baler is designed to produce a bale approximately 900 x 800 x 1400 in size with a weight of 400-600 kg's (depending on material) and handle approximately 400-800 tons per month. The RMB-36DA is designed to be manually loaded, tied and discharged.
Special variable flow, high performance piston pump with constant horsepower controller.
Platen guided at rear and fitted with four heavy duty platen rollers.
Chamber floor bottom and side wear plates.
Typically conveyor fed. Safety hand feed hopper shown above.
SPECIFICATION
|
Series |
RMB-36DA |
|
Type |
Horizontal – Top Loading |
|
Charge Chamber opening size |
1400 x 810mm |
|
Bale size |
900 x 800 x 1400mm |
|
Bale weight / mass |
320 to 600kg (Dependent upon product) |
|
Number of bale ties |
4 |
|
Bale Ejection |
Automatic |
|
Cycle time |
Automatic - 16 seconds (No Load) |
|
Ram Thrust |
34 Tons |
|
Normal Working Pressure |
230 bar |
|
Pump Type |
Piston pump with pressure, flow & torque compensation |
|
Rated Output |
160 - 360 Tons per month |
|
Pump Size |
71cc/rev, 103 l/min |
|
Motor Size |
22KW |
|
Cylinder Specifications (Bore x Rod x Stroke) |
125 x 90 x 1600mm |
|
Hydraulic Oil Cooler |
Standard |
|
Oil Tank Capacity |
440 Litres |
|
Shipping Weight |
Approx. 5200 kg |
|
Electrical |
|
|
Electrical Supply Requirements |
380V 3 Phase 4 Pole 50 Hz |
|
Power Point |
5 Pin Plug & Socket 32 amp |
|
Dimensions |
|
|
L - Length |
5155 mm |
|
W - Width ( Including the Chute) |
1386 mm |
|
H - Height ( Including the Chute) |
2250 mm |
|
Country of Origin |
Manufactured in South Africa |
All specifications are for indicative purposes only and subject to change without prior notice
